Door CAD Block 02 — Double-Acting Double Doors in Plan
Plan of double-acting double doors with swing circles both ways, one block about 5.2 units long.
Up to 100 library downloads per day across all libraries. Resets at 00:00 UTC.
DWG is the original file. DXF is written from it on request. Open in CAD loads it into the free browser CAD — nothing to install, no account.
Specifications
- Format
- DWG R2018 · DXF R2000 on request
- Units
- metresread from the geometry — the file's unit flag says inches, but it is metre-sized
- Size
- 5 × 2.5 m (width × height)
- Entities
- 2 — 1 block reference and 1 paragraph text
- Layers
- A-Door
- Block definitions
- none — plain geometry
- File size
- 34 KB
- Updated
About this block
Seen from above, this block shows a run of double-acting leaves: the outer leaves swing through 180 degrees toward the outside, and the inner pair swings both ways, so their paths are drawn as full circles either side of the opening. Short wall stubs close the composition at each end. It is one block definition named AP0E04 made of 22 lines and 4 arcs on a layer called A-Door, and it spans 5.2 by 2.0 drawing units, which reads as metres for leaves about one metre wide.
Hospitals, kitchens and back-of-house corridors use double-acting doors, and this symbol shows their full swing so clearances can be checked in plan at 1:50 and 1:100. Insert it on the wall centreline, trim your wall to the stubs, and scale by 1000 in a millimetre drawing. If only one pair is needed, explode a copy and delete the outer leaves; the arcs are simple objects and re-block cleanly.
