Workplace Hazard Warning Sign CAD Blocks
Twenty workplace hazard plates: yellow warning triangles with Spanish captions on white backing.
Up to 100 library downloads per day across all libraries. Resets at 00:00 UTC.
DWG is the original file. DXF is written from it on request. Open in CAD loads it into the free browser CAD — nothing to install, no account.
Specifications
- Format
- DWG R2018 · DXF R2000 on request
- Units
- inches
- Size
- 15.3 × 8.9 in (width × height)
- Entities
- 419 — 209 polylines, 83 hatches, 43 lines, 26 splines, 21 paragraph texts, 20 arcs, 14 circles, 2 ellipses and 1 text label
- Layers
- INCENDIOnegroamarilloLayer1
- Block definitions
- none — plain geometry
- File size
- 150 KB
- Updated
About this block
Twenty warning plates, each a yellow triangle with a black border and pictogram set on a white portrait backing, captioned in Spanish beneath. The hazards read RIESGO ELECTRICO, SUPERFICIE CALIENTE, RIESGO DE CORTES, CON SUS MANOS, RIESGO DE ATROPELLO, RIESGO DE SER APLASTADO, ARRANQUE AUTOMATICO, GOLPE CONTRA OBJETOS INMOVILES and MOVILES, PELIGRO DE OBSTACULOS, PELIGRO DE CAIDAS, PISO RESBALOSO, CAIDA DE OBJETOS, RIESGO DE EXPLOSION, ATMOSFERA EXPLOSIVA and SUSTANCIAS O MATERIAS TOXICAS.
Health and safety drawings use these on factory and warehouse layouts, plant rooms, construction site plans and machine guarding details, marking where a hazard sign must be fixed and what it says. The two headings, ATENCION and CUIDADO, separate severity, so keep the wording as drawn if your site follows that convention. On a plant layout at 1:100 the plate itself is too small to read: place the triangle alone as a marker and put the caption in a schedule keyed by number.
Colour is handled by layer, not by object: layers named amarillo and negro carry the yellow fill and the black pictogram, and a layer called INCENDIO holds the fire-related plates. That makes recolouring the set a two-click job, and freezing INCENDIO isolates the fire hazards on their own. The 83 hatches are the fills; explode one and you lose the ability to recolour it. The sheet spans 15.3 by 8.9 legend units, so scale a plate to your standard sign size on insertion.
