Multi-Sport Stadium — Floor Plan, Sections and Elevations
Stadium floor plan on a numbered grid with arena, stands and stairs, plus four roof sections and elevations.
Up to 100 library downloads per day across all libraries. Resets at 00:00 UTC.
DWG is the original file. DXF is written from it on request. Open in CAD loads it into the free browser CAD — nothing to install, no account.
Specifications
- Format
- DWG R2018 · DXF R2000 on request
- Units
- metres
- Entities
- 2,759 — 1,800 lines, 296 block references, 249 polylines, 168 arcs, 152 text labels, 78 hatches, 12 circles and 4 paragraph texts
- Layers
- wallinwallaxkaf1kaf2kaf3furdoor & winstairsgradientFURN1+10 more
- Block definitions
- none — plain geometry
- File size
- 540 KB
- Updated
About this block
The left half of the sheet stacks four drawings of the roof: two elevations of the arched steel structure and two sections marked A-A and B-B, with stands drawn in yellow and blue. The right half is the floor plan, a rounded rectangle on grid axes 1 to 11 and A to D with an arena, seating tiers, stair cores and people blocks (Man051, Man053) for scale. There are 2,759 model entities plus 59 block definitions across 22 layers, including wall, inwall, stairs, fur, door & win, section and dimen. Units are metres and the plan spans about 216 by 116.
Use it as a reference for an indoor arena or covered stadium: the plan shows how stair cores are placed around an oval bowl, and the sections show the arch rise and stand rake. Freeze the dimen and section layers to get a clean plan for a site study. Because the units are already metres, it drops into a metre-based site plan at scale 1.
