People CAD Blocks — Scale Figures in Plan and Elevation

Twenty-three files of human figures for scale. Nineteen are a single person, standing or walking, seen from above as a head-and-shoulders symbol or from the side as a filled silhouette, between 1.2 and 2.3 units tall, which reads as metres for an adult. Four of those are drawn as one polyline each, so they add almost nothing to a busy drawing. The rest are groups: a five-figure set, a four-person cluster, four swimmers for a pool plan, and a sheet holding thirteen figure inserts alongside 245 lines of loose linework.

Figures give a drawing its scale in elevations, sections and perspectives, and the plan symbols populate seating layouts, waiting areas and circulation routes at 1:50 to 1:200. Place them where a person would actually stand rather than evenly along a facade, and keep the count low, since two or three people in a section read better than a crowd. Source layers come from Vietnamese, Spanish and Turkish drawings — DIEN HOA, NGUOI, OP-AMBI-GENTE, insan — so move the inserts onto an entourage layer of your own before you plot.

23 blocks · every one as DWG and DXF · free, no sign-up
